Optional Investment Scheme Of Automatic Brick Machine

For Commercial Use

  • 1

    This plan is mainly to provide investors with a complete brick machine production line, starting from the production of raw materials needed for the production of bricks;

  • 2

    And then to the use of AJ-50 concrete batching plant to produce one of the raw materials—-concrete;

  • 3

    And then by the brick machine to produce bricks that investors or investors’ customers need;

  • 4

    Finally, the discarded bricks will be sent back to the crusher plant of the first process for recycling, and so on, to achieve efficient brick machine production;

  • one wheel loader
  • one impact crusher
  • one screening system
  • five belt conveyors
  • one AJ-50 batching plant
  • forklift truck
  • one ABM-10S brick machine production line

(The configuration can be changed based on customer requirements and rationality.)


Commercial Automatic Brick Production Line

Profits:

In the whole process, investors can not only sell bricks , but also all kinds of raw materials produced by the crushing plant, such as sand and stone, and can sell concrete mixtures to achieve three benefits with one production line.

Brick making machine
Crushing plant
Concrete batching production line

Sell bricks
Sand and stone
Sell concrete mixtures

Working Procedure Of Commericial Brick Production Line


Crushing Production Line

Crushing

  • 1

    Feeding. First of all, the wheel loader will transport the raw materials (<250mm) to the vibrating feeder;

  • 2

    Crushing. And then transport materials to the APF1010 impact crusher;

  • 3

    Finished products. After crushing, the material will enter the screening system, the size is greater than 30mm, according to the size of the broken material screening, the same particle size will be discharged by the same belt conveyor, they are 0-10mm, 10-20mm, and 20-30mm;

Moreover, if want to sell the sand and stone, you can use a dumper.

Vibrating Screen

Vibrating Feeder

Model:  APG-0724Z
Max feed size:  450mm
Capacity:  30-80tph
Overall dimensions(L*W*H):  2480×1130×990
Power:  2*1.5kw
Weight:  2500kg
Amount:  one set
Impact Crusher

Impact Crusher

Model:  APF1010
Max feed size:  250mm
Feed opening size:  400×1080mm
Capacity:  50-80tph
Power:  75kw
Rotor Size:  Φ1000×1050mm
Weight:  122000kg
Vibrating Feeder

Vibrating Screen

Model:  APS-1548 Y3
Screen size:  4800×1500mm
Mesh size:  3-80mm
Capacity:  30-100tph
Vibrating frequency:  750r/min
Weight:  3800kg
Features:  3 decks


Concrete Batching Production Line

Mixing

This part will use AJ-50 stationary concrete batching plant. The followings are the compete mixing process.

  • 1

    The operator should use the wheel loader to transport the sand and stone produced by the impact crusher to the PLD1600 concrete batching machine;

  • 2

    And there is a hopper lifting the batched aggregates to the AJS1000 twin shaft mixer;
    At the same time, cement or fly ash will be discharged from the welded type cement silo to weighing system, after weighing, discharged to the mixer;

  • 3

    Add the weighed additives, aggregate, powder, and water will be mixed evenly in the twin shaft concrete mixer.

  • 4

    After the stipulated time, the concrete mixture will be discharged to the block machine through a belt conveyor;

  • 5

    What’s more, if you want to sell concrete, you can use a concrete transit mixer to transport concrete to your clients;



Brick-making production line

Brick-making

  • 1

    Firstly, the concrete produced by the AJ-50 concrete batch plant enter the hopper of the brick making machine;

  • 2

    The hopper will open automatically and mixture will enter the distributing machine;

  • 3

    The distributing machine will distribute the materials to mold frame, again by the host system through automatic vibrating force and pressure to complete the brick forming;

  • 4

    4.After palletizing system, through the automatic palletizing machine, the bricks will folded (4-5 layer) per pallet;

  • 5

    5.Then operators will transport the bricks to brick maintenance site, and water maintenance for 7-10 days, finally, sell the finished bricks to clients.


For Small Projects

here is a small brick production line, this plan is mainly for small projects. Main process are mixing and brick-making:

  • 1

    AJ-25 small concrete batching plant produced the fresh concrete mixture;

  • 2

    And transport the concrete through a belt conveyor to the hopper of the block machine;

  • 3

    Then finish the whole brick-making;

  • one set of AJ-25 small concrete batch plant
  • one ABM-4SE block making machine

(The configuration can be changed based on customer requirements and rationality.)


Small Projects for brick production line
AJ-25 small concrete batching plant

AJ-25

Twin shaft mixer JS500
Cement silo Welded type
Concrete batching machine Four-bin
Screw conveyor 219
Discharging height 3.8
Max.aggregate size 40mm
Control Mode Automatic control
ABM-4SE block making machine

ABM-4SE

Brick Size(L*W*H) Cycle Molding Pcs/Hr Daily Output/8h
paving blocks 200*100*60 18-23s 4852-6200 38816-49600
interlocking bricks 200*160*60 18-23s 3287-4200 26296-33600
solid blocks 240*115*53 15-17s 11011-12480 88088-99840
hollow bricks 390*190*190 20-25s 1440-1800 11520-14400
